ArWoWear T31 Flame Arc Pro
89% Cotton 10% Polyamide 1% Carbon, Flame Retardant, Antisatic Fabric, 330 gr/m'2
330 g/m², 89% Cotton 10% Polyamide 1% Carbon, VAT Dyed, Flame Retardant (100 Wash Resistant), Antistatic, 3/1S Twill Fabric
Description
ArWoWear T31 Flame Arc Pro is heavy weight 330 gr/m', 89% Cotton 10% Polyamide 1% Carbon,, vat dyed, flame retardant, antistatic workwear fabric.
It has flame retardant function with EN ISO 11612 and EN ISO 11611 certification.
Due to carbon fibers used on the back side of the fabric it has antistatic certification. (EN 1149-5)
Protection against thermal hazards of electrical arc. (EN 61482-1-2)
It is durable up to 100 washing.
Standards & functions
Care instructions
Technical parameters24
| Parameter | Value | Method / standard |
|---|---|---|
| Fiber | 89% Cotton (CO) 10% Polyamide 1% Carbon(CF) | EN ISO 2076 |
| Yarn | Warp:20/2Ne ; Weft:20/2Ne | EN ISO 2060 |
| Weight | 330 ±10 g/m² | EN ISO 3081 |
| Width | 1600 ±20 mm | EN ISO 3932 |
| Tensile Strength | Warp>1400N; Weft>1200N | EN ISO 13934-1 |
| Tear Strength | Warp>30N; Weft>25N | EN ISO 13937-2 |
| Dimensional Change | -3% < Length < +3% ; -3% < Width < +3% | EN ISO 5077 |
| Rubbing Fastness | 4-5 | EN ISO 105 X12 |
| Perspiration Fastness | 4-5 | EN ISO 105 E04 |
| Washing Fastness | 4-5 | EN ISO 105 C06 |
| Dry Cleaning Fastness | 4-5 | EN ISO 105 D01 |
| Hypochlorite Fastness | 4-5 | EN ISO 105 N01 |
| Peroxide Fastness | 4-5 | EN ISO 105 N02 |
| Hot Press Fastness | 4-5 | EN ISO 105 X11 |
| Light Fastness | 6-7 | EN ISO 105 B02 |
| Perspiration Light Fast. | 4-5 | EN ISO 105 B07 |
| pH | 6.0 | EN ISO 3071 |
| Azo Test | No Azo Colorants. | EN ISO 14362-1 |
| Application | Flame Retardant Shirt | — |
| Quality Management | Done | ISO 9001 |
| Flame and Heat Protection | Yes | EN ISO 11612 |
| Welding Protection | Yes | EN ISO 11611 |
| Arc Protection | Class 1 (4kA) | EN ISO 61482-1-2 |
| ATPV | > 11 cal/cm² | EN ISO 61482-1-1 |
Colours & article numbers
| Colour | Finish | Article no. |
|---|---|---|
| PNIND 25043 | STANDARD | Arc Pro-4792 |
| PNIND 34467 | STANDARD | Arc Pro-4793 |
| PNIND 66235 | STANDARD | Arc Pro-4794 |
| PNIND 34469 | STANDARD | Arc Pro-4795 |
| PNIND 59884 | STANDARD | Arc Pro-4796 |
| PNIND 96676 | STANDARD | Arc Pro-4797 |
| PNIND 59886 | STANDARD | Arc Pro-4798 |
| PNIND 96678 | STANDARD | Arc Pro-4799 |
| PNIND 59889 | STANDARD | Arc Pro-4800 |
| PNIND 66237 | STANDARD | Arc Pro-4801 |
