Catalogue · ArWoWear Flame Arc Pro
ArWoWear T1 Flame Arc Pro
99% Cotton 1% Carbon Twill, Flame Retardant Antistatic Fabric, 220 gr/m'2
220 g/m², 99% Cotton 1% Carbon, VAT Dyed, Flame Retardant (100 Wash Resistant), Antistatic, 2/1S Twill Fabric
Description
ArWoWear T1 Flame Arc Pro is light weight 220 gr/m', 99% cotton 1% Carbon, vat dyed, flame retardant, antistatic workwear fabric.
It has flame retardant function with EN ISO 11612 certification.
Due to carbon fibers used on the back side of the fabric it has antistatic certification. (EN 1149-5)
It is durable up to 100 washing.
Standards & functions
Care instructions
Technical parameters22
| Parameter | Value | Method / standard |
|---|---|---|
| Fiber | 99% Cotton (CO) 1%Carbon(CF) | EN ISO 2076 |
| Yarn | Warp:40/2Ne ; Weft:40/2Ne | EN ISO 2060 |
| Weight | 220 ±10 g/m² | EN ISO 3081 |
| Width | 1600 ±20 mm | EN ISO 3932 |
| Tensile Strength | Warp>800N; Weft>600N | EN ISO 13934-1 |
| Tear Strength | Warp>20N; Weft>15N | EN ISO 13937-2 |
| Dimensional Change | -3% < Length < +3% ; -3% < Width < +3% | EN ISO 5077 |
| Rubbing Fastness | 4-5 | EN ISO 105 X12 |
| Perspiration Fastness | 4-5 | EN ISO 105 E04 |
| Washing Fastness | 4-5 | EN ISO 105 C06 |
| Dry Cleaning Fastness | 4-5 | EN ISO 105 D01 |
| Hypochlorite Fastness | 4-5 | EN ISO 105 N01 |
| Peroxide Fastness | 4-5 | EN ISO 105 N02 |
| Hot Press Fastness | 4-5 | EN ISO 105 X11 |
| Light Fastness | 6-7 | EN ISO 105 B02 |
| Perspiration Light Fast. | 4-5 | EN ISO 105 B07 |
| pH | 6.0 | EN ISO 3071 |
| Azo Test | No Azo Colorants. | EN ISO 14362-1 |
| Application | Flame Retardant Shirt | — |
| Quality Management | Done | ISO 9001 |
| Flame and Heat Protection | Yes | EN ISO 11612 |
| Antistatic | Yes | EN ISO 1149-5 |
Colours & article numbers
| Colour | Code / PIND | Finish | Article no. |
|---|---|---|---|
| Orange | PIND-33318 | STANDARD | Arc Pro-5337 |
| Dark Green | PIND-64865 | STANDARD | Arc Pro-5338 |
| Red | PIND-33320 | STANDARD | Arc Pro-5339 |
| Dark Blue | PIND-57745 | STANDARD | Arc Pro-5340 |
| Black | PIND-95470 | STANDARD | Arc Pro-5341 |
| Navy | PIND-59001 | STANDARD | Arc Pro-5342 |
| Grey | PIND-95796 | STANDARD | Arc Pro-5343 |
