Aramid D5 180 Rb

46% meta Aramid 50% para Aramid 2% Pbo 2% Carbon ripstop fabric , 180 gr/m'2

180 g/m², 46% meta Aramid 50% para Aramid 2% Pbo 2% Carbon, Inherent Flame Retardant, Antistatic, Ripstop-twill Fabric Aramid fabric

EN ISO 11612EN ISO 11611EN 1149EN 13034EN 469EN 15614OEKO-TEX 100
Aramid D5 180 Rb

Description

46% meta Aramid 50% para Aramid 2% Pbo 2% Carbon.

Inherent flame retardant ripstop-twill fabric

for woodland firefighters. Aramid D5 180 Rb is designed for woodland, wild forest fire condtions with high p-aramid and pbo content.

Inherent flame retardant fabric with EN ISO 11612 certification.

Antistatic (EN 1149-5) certified

Resistant to most industrial chemicals. (EN ISO 13034)

Standards & functions

Oeko Tex Standard 100
Oeko Tex Standard 100
EN 11611
EN 11611
EN 1149
EN 1149
EN 15614
EN 15614
EN 13034
EN 13034

Care instructions

60'C Machine WashNo Chlorine Based BleachingCan Be Tumble Dried On Low Heat SettingMaximum 150'C Warm IronSuitable for Dry Cleaning

Technical parameters24

ParameterValueMethod / standard
Fiber46% m-Aramid (m-AR) 50% p-Aramid (p-AR) 2% PBO (Pbo) 2% Carbon(CF)EN ISO 2076
YarnWarp:36/2Ne; Weft:36/2NeEN ISO 2060
Weight180 ±15 g/m²EN ISO 3081
Width1600 ±20 mmEN ISO 3932
Tensile StrengthWarp > 1000N; Weft > 1000NEN ISO 13934-1
Tear StrengthWarp>100N ; Weft>100NEN ISO 13937-2
Dimensional Change-3% < Length < +3% ; -3% < Width < +3%EN ISO 5077
Rubbing Fastness4-5EN ISO 105 X12
Perspiration Fastness4-5EN ISO 105 E04
Washing Fastness4-5EN ISO 105 C06
Dry Cleaning Fastness4-5EN ISO 105 D01
Hypochlorite Fastness4-5EN ISO 105 N01
Peroxide Fastness4-5EN ISO 105 N02
Hot Press Fastness4-5EN ISO 105 X11
Light Fastness4-5EN ISO 105 B02
Perspiration Light Fast.4-5EN ISO 105 B07
pH4,0-9.0EN ISO 3071
Azo TestNo Azo Colorants.EN ISO 14362-1
ApplicationForest Firefigters's Jacket—
Quality ManagementDoneISO 9001
Flame and Heat ProtectionYesEN ISO 11612
AntistaticYesEN ISO 1149-5
Forest FirefightersYesEN ISO 15614
Chemical ResistantYesEN ISO 13034

Colours & article numbers

ColourFinishArticle no.
NaturalSTANDARDAramid D5 180 Rb-5694

Applications

Woodland Firefighter Suits
Woodland Firefighter Suits
Woodland Firefighter Suits
