Aramid D0 150

Aramid Fabric, 93% meta Aramid 5% para Aramid 2% Carbon , 150 gr/m'2

150 g/m², 93% m-Aramid 5% p-Aramid 2% Carbon, Inherent Flame Retardant, Antistatic, 1/1 Plain Fabric Aramid fabric

EN ISO 11612EN ISO 11611EN 1149EN 13034OEKO-TEX 100

Description

150 g/m², 93% m-Aramid, 5% p-Aramid, 2% Carbon.

Inherent flame retardant fabric

for firefighters, military pilot costumes, oil and gas industry workers.

Inherent flame retardant fabric with EN ISO 11612 certification.

Antistatic (EN 1149-5) certified

Resistant to most industrial chemicals. (EN ISO 13034)

Standards & functions

Care instructions

Parameter	Value	Method / standard
Fiber	93% m-Aramid (m-AR) 5% p-Aramid (p-AR) 2% Carbon(CF)	EN ISO 2076
Yarn	Warp:40/2Ne; Weft:40/2Ne	EN ISO 2060
Weight	150 ±5 g/m²	EN ISO 3081
Width	1600 ±20 mm	EN ISO 3932
Tensile Strength	Warp > 750N; Weft > 600N	EN ISO 13934-1
Tear Strength	Warp>40N ; Weft>30N	EN ISO 13937-2
Dimensional Change	-3% < Length < +3% ; -3% < Width < +3%	EN ISO 5077
Rubbing Fastness	4-5	EN ISO 105 X12
Perspiration Fastness	4-5	EN ISO 105 E04
Washing Fastness	4-5	EN ISO 105 C06
Dry Cleaning Fastness	4-5	EN ISO 105 D01
Hypochlorite Fastness	4-5	EN ISO 105 N01
Peroxide Fastness	4-5	EN ISO 105 N02
Hot Press Fastness	4-5	EN ISO 105 X11
Light Fastness	4-5	EN ISO 105 B02
Perspiration Light Fast.	4-5	EN ISO 105 B07
pH	6.0	EN ISO 3071
Azo Test	No Azo Colorants.	EN ISO 14362-1
Application	Pilot Costumes	—
Quality Management	Done	ISO 9001
Flame and Heat Protection	Yes	EN ISO 11612
Antistatic	Yes	EN ISO 1149-5
Chemical Resistant	Yes	EN ISO 13034
