Catalogue · Aramid Knit
Aramid D50 Pike
93% m-Aramid 5% p-Aramid 2% Carbon, Inherent Pique Flame Retardant Antistatic Fabric
220 g/m², 93% m-Aramid 5% p-Aramid 2% Carbon, Inherent Flame Retardant
Description
Antistatic Pique Knit Fabric 93% m-Aramid 5% p-Aramid 2% Carbon, inherent flame retardant antistatic pique knit fabric. Aramid d50 Pike fabric is universal flame retardant knit fabric for many applications.
Aramid D50 Pike is inherent flame retardant with EN 11612 certification.
Suitable for antistatic applications, certified for EN ISO 1149.
It provides arc flash protection with EN 61482 class 1 (4 kA) certification.
Standards & functions
Care instructions
Technical parameters23
| Parameter | Value | Method / standard |
|---|---|---|
| Fiber | 93% m-Aramid (m-AR) 5% p-Aramid (p-AR) 2% Carbon (CF) | EN ISO 2076 |
| Yarn | 40/2 Ne Combed | EN ISO 2060 |
| Weight | 220 ±5 g/m² | EN ISO 3081 |
| Width | 1800 ±20 mm | EN ISO 3932 |
| Bursting strength | > 1200 kPa(kN/m² ) | EN ISO 13938-1 |
| Dimensional Change | -5% < Length < +5% ; -5% < Width < +5% | EN ISO 5077 |
| Rubbing Fastness | 4-5 | EN ISO 105 X12 |
| Perspiration Fastness | 4-5 | EN ISO 105 E04 |
| Washing Fastness | 4-5 | EN ISO 105 C06 |
| Dry Cleaning Fastness | 4-5 | EN ISO 105 D01 |
| Hypochlorite Fastness | 4-5 | EN ISO 105 N01 |
| Peroxide Fastness | 4-5 | EN ISO 105 N02 |
| Hot Press Fastness | 4-5 | EN ISO 105 X11 |
| Light Fastness | 4-5 | EN ISO 105 B02 |
| Perspiration Light Fast. | 4-5 | EN ISO 105 B07 |
| pH | 4.0-7.5 | EN ISO 3071 |
| Azo Test | No Azo Colorants. | EN ISO 14362-1 |
| Application | Flame Retardant Universal T-Shirt | — |
| Quality Management | Done | ISO 9001 |
| Antistatic | Done | EN ISO 1149-5 |
| Flame and Heat Protection | Done | EN ISO 11612 |
| Arc Protection | Class 1 (4kA) | EN ISO 61482-1-2 |
| ATPV | > 7 cal/cm² | EN ISO 61482-1-1 |
Colours & article numbers
| Colour | Finish | Article no. |
|---|---|---|
| Navy | STANDART | Aramid D50 Pike - 5689 |
| Grey | STANDART | Aramid D50 Pike - 5690 |
Applications
Other variants in this familyAramid Knit · 1
Send us your fabric specification.
Composition, weight, required standards, estimated volume — we respond with an offer, a technical data sheet and test results.
