Aramid D2 260 El

Aramid Elasthane Fabric, 88% meta Aramid 5% para Aramid 2% Carbon 5% Elastane , 260 gr/m'2

260 g/m², 88% m-Aramid 5% p-Aramid 2% Carbon 5% Elastane, Inherent Flame Retardant, Elasthane, Antistatic, 3/1S Twill Fabric Aramid elasthane twill fabric

EN ISO 11612EN 1149EN 61482EN 13034OEKO-TEX 100
Aramid D2 260 El

Description

260 g/m², 88% m-Aramid 5% p-Aramid 2% Carbon 5% Elastane.

Inherent flame retardant fabric

for military application and firefighters with ultra comfort.

Inherent flame retardant fabric with EN ISO 11612 certification.

Suitable for antistatic applications. (EN 1149-3)

Protection against thermal hazards of electrical arc. (EN 61482-1-2)

Resistant to most industrial chemicals. (EN ISO 13034)

Standards & functions

Oeko Tex Standard 100
Oeko Tex Standard 100
EN 11612
EN 11612
EN 1149
EN 1149
EN 61482
EN 61482
EN 13034
EN 13034

Care instructions

60'C Machine WashNo Chlorine Based BleachingCan Be Tumble Dried On Low Heat SettingMaximum 150'C Warm IronSuitable for Dry Cleaning

Technical parameters25

ParameterValueMethod / standard
Fiber88% m-Aramid (m-AR) 5% p-Aramid (p-AR) 2% Carbon(CF) 5% Elastane (El)EN ISO 2076
YarnWarp:30/2Ne; Weft:30/2NeEN ISO 2060
Weight260 ±5 g/m²EN ISO 3081
Width1400 ±20 mmEN ISO 3932
Tensile StrengthWarp > 1500N; Weft > 1000NEN ISO 13934-1
Tear StrengthWarp>70N ; Weft>60NEN ISO 13937-2
Dimensional Change-3% < Length < +3% ; -3% < Width < +3%EN ISO 5077
Rubbing Fastness4-5EN ISO 105 X12
Perspiration Fastness4-5EN ISO 105 E04
Washing Fastness4-5EN ISO 105 C06
Dry Cleaning Fastness4-5EN ISO 105 D01
Hypochlorite Fastness4-5EN ISO 105 N01
Peroxide Fastness4-5EN ISO 105 N02
Hot Press Fastness4-5EN ISO 105 X11
Light Fastness4-5EN ISO 105 B02
Perspiration Light Fast.4-5EN ISO 105 B07
pH4.0 - 7.5EN ISO 3071
Azo TestNo Azo Colorants.EN ISO 14362-1
ApplicationMilitary Applications—
Quality ManagementDoneISO 9001
Flame and Heat ProtectionYesEN ISO 11612
AntistaticYesEN ISO 1149-5
Arc ProtectionClass 1 (4kA)EN ISO 61482-1-2
ATPV> 12 cal/cm²EN ISO 61482-1-1
Chemical ResistantYesEN ISO 13034

Colours & article numbers

ColourArticle no.
NavyPP-58628

Applications

Cordura(R) Reinforced Aramid Firefighter Turnout Gear
Cordura(R) Reinforced Aramid Firefighter Turnout Gear
Cordura(R) Reinforced Aramid Firefighter Turnout Gear
