Ariteks — Functional Technical Fabrics

Catalogue · ArOx

Arox T5 Multi

75% Polyester 23% Polyurethane 2% Carbon Milky Coated, Inherent Flame Retardant, Antistatic, High Visible Waterproof Oxford Fabric

250 g/m², 75% Polyester 23% Polyurethane 2% Carbon, Inherent Flame Retardant, Antistatic, Waterproof, Breathable, High Visible, 1/1 Plain Woven Fabric

EN ISO 20471EN ISO 14116EN 1149EN 13034EN 343OEKO-TEX 100
Arox T5 Multi

Description

75% Polyester 23% Polyurethane 2% Carbon milky back coated, flame retardant, antistatic, high visible, water repellent, waterproof, breathable oxford fabric.

Arox T5 Multi fabrics are used for outdoor jackets, trousers and bodywarmers which has waterproof and flame retardant functions. The fabric is inherent flame retardant polyester with antistatic carbon grids.

Certified for EN ISO 20471, EN 343, EN 1149-5, EN 14116 and EN 13034

Standards & functions

Oeko Tex Standard 100
Oeko Tex Standard 100
EN 20471
EN 20471
EN 13034
EN 13034
EN 343
EN 343
EN 1149
EN 1149
EN 14116
EN 14116

Care instructions

60'C Machine WashNo Chlorine Based BleachingCan Be Tumble Dried On Low Heat SettingMaximum 150'C Warm IronSuitable for Dry Cleaning

Technical parameters21

ParameterValueMethod / standard
Fiber75% Polyester (PES) 23% Polyurethane (PU) 2% Carbon (CF)EN ISO 2076
Yarn300 DenierEN ISO 2060
Weight250 ±5 g/m²EN ISO 3081
Width1600 ±20 mmEN ISO 3932
Tensile StrengthWarp > 1000N ; Weft > 800NEN ISO 13934-1
Tear StrengthWarp > 30N ; Weft > 25NEN ISO 13937-2
Dimensional Change-3% < Length < +3% ; -3% < Width < +3%EN ISO 5077
Rubbing Fastness4-5EN ISO 105 X12
Perspiration Fastness4-5EN ISO 105 E04
Washing Fastness4-5EN ISO 105 C06
Dry Cleaning Fastness4-5EN ISO 105 D01
Hypochlorite Fastness4-5EN ISO 105 N01
Hot Press Fastness4-5EN ISO 105 X11
pH6.0EN ISO 3071
Azo TestNo Azo Colorants.EN ISO 14362-1
ApplicationHi Vis Raincoats—
Quality ManagementDoneISO 9001
High VisibilityDoneEN ISO 20471
Chemical ResistantDoneEN ISO 13034
WaterproofDoneEN ISO 343
AntistaticDoneEN ISO 1149-5 (EN 1149-3)

Colours & article numbers

ColourCode / PINDFinishArticle no.
YellowPT-23603HIGH VISIBLEArox T5 Multi-5080
OrangePT-22970HIGH VISIBLEArox T5 Multi-5081
RedPT-33280-1HIGH VISIBLEArox T5 Multi-5082
NavyPT-57753STANDARDArox T5 Multi-5083
BlackPT-95503STANDARDArox T5 Multi-5084

Applications

FR, waterproof, Safety Jacket EN 20471
FR, waterproof, Safety Jacket EN 20471
FR, waterproof, Safety Jacket EN 20471

Other variants in this familyArOx · 4

Arox T1 Static Pro

Arox T1 Static Pro

110 g/m² · 99% PES 1% CF

Arox T2 Static Pro

Arox T2 Static Pro

160 g/m² · 99% PES 1% CF

Arox T2 WR

Arox T2 WR

160 g/m² · 100% PES

Arox T4 WR/WP

Arox T4 WR/WP

210 g/m² · 75% PES 25% PU

Send us your fabric specification.

Composition, weight, required standards, estimated volume — we respond with an offer, a technical data sheet and test results.
