Ari Gabardin 245
100% AriPam uv resistant twill fabric
245 g/m², 100% AriPam, Uv protective, 3/1 S Twill Woven Fabric
EN ISO 20471EN 343EN 13758OEKO-TEX 100
Description
100% AriPam spun twill fabric.
It is used as a lining inside of the shoes.
Ari Gabardin 245 can also be used for outdoor jackets, safety jackets, pants and trousers.
Standards & functions
Care instructions
Technical parameters17
| Parameter | Value | Method / standard |
|---|---|---|
| Fiber | 100% AriPam | EN ISO 2076 |
| Yarn | 30/2 Ne | EN ISO 2060 |
| Weight | 245 ±10 g/m² | EN ISO 3081 |
| Width | 1600 ±20 mm | EN ISO 3932 |
| Tensile Strength | Warp > 1800N ; Weft > 1200N | EN ISO 13934-1 |
| Tear Strength | Warp > 35N ; Weft > 40N | EN ISO 13937-2 |
| Dimensional Change | -3% < Length < +3% ; -3% < Width < +3% | EN ISO 5077 |
| Rubbing Fastness | 4-5 | EN ISO 105 X12 |
| Perspiration Fastness | 4-5 | EN ISO 105 E04 |
| Washing Fastness | 4-5 | EN ISO 105 C06 |
| Dry Cleaning Fastness | 4-5 | EN ISO 105 D01 |
| Hypochlorite Fastness | 4-5 | EN ISO 105 N01 |
| Hot Press Fastness | 4-5 | EN ISO 105 X11 |
| pH | 4,0 - 7,5 | EN ISO 3071 |
| Azo Test | No Azo Colorants. | EN ISO 14362-1 |
| Application | Lining for Shoes | — |
| Quality Management | Done | ISO 9001 |
Colours & article numbers
| Colour | Code / PIND | Finish |
|---|---|---|
| Navy | PT-5011717-1 | STANDARD |
| Black | PT-95503-1 | STANDARD |
| Grey | PT-97892-1 | STANDARD |
