Catalogue · ArDura 2
ArDura 500 CG
Pa6.6 woven fabric for Bomb Disposal Suits
350 g/m², 100% Pa 6.6, Water Repellent, Antibacterial, Herringbone Woven Fabric
Description
ArDura 500 CG is 100% polyamide 6.6 woven fabric for bomb disposal suits, military, police and gendarme wear and nail proof pockets on workwear.
The Pa6.6 high tenacity fibers gives for extra protection for bomb disposal clothing.
The fabric has water and oil repellent function.
It's used mostly for application which requires ultra durability.
The antibacterial function is very usefull to eliminate all kind of odor formation during work.
Standards & functions
Care instructions
Technical parameters22
| Parameter | Value | Method / standard |
|---|---|---|
| Fiber | 100% Polyamide 6.6 (PA 6.6) | EN ISO 2076 |
| Yarn | 500 Denier | EN ISO 2060 |
| Weight | 350 ±10 g/m² | EN ISO 3081 |
| Width | 1600 ±20 mm | EN ISO 3932 |
| Tensile Strength | Warp>3500N; Weft>2500N | EN ISO 13934-1 |
| Tear Strength | Warp>250N; Weft>220N | EN ISO 13937-2 |
| Dimensional Change | -3% < Length < +3% ; -3% < Width < +3% | EN ISO 5077 |
| Abrasion Resistance | @50000 | EN ISO 12947-2 |
| Rubbing Fastness | 4-5 | EN ISO 105 X12 |
| Perspiration Fastness | 4-5 | EN ISO 105 E04 |
| Washing Fastness | 4-5 | EN ISO 105 C06 |
| Dry Cleaning Fastness | 4-5 | EN ISO 105 D01 |
| Hypochlorite Fastness | 4-5 | EN ISO 105 N01 |
| Hot Press Fastness | 4-5 | EN ISO 105 X11 |
| Light Fastness | 4 | EN ISO 105 B02 |
| Weathering Fastness | 6+ | EN ISO 105 B04 |
| pH | 4-7 | EN ISO 3071 |
| Azo Test | No Azo Colorants | EN ISO 14362-1 |
| Allergenic Dyestuffs | Not Detected | EN ISO 14362-1 |
| Application | Bomb Disposal Suits | — |
| Quality Management | Done | ISO 9001 |
| Spray Test | ISO 5 | EN ISO 24920 |
Colours & article numbers
| Colour | Code / PIND | Finish | Article no. |
|---|---|---|---|
| Black | PN-97824 | STANDART | ArDura 500 CG-5991 |
