ArDolu
95% Polyester 5% Pu bonded fabric
210 g/m², 95% Polyester 5% Elastane, 3 layer laminated, Bonded Fabric
EN ISO 20471EN 343OEKO-TEX 100
Description
ArDolu is 95% polyester 5% pu bonded fabric. The top layer is woven fabric, the middle layer is breathable tpu membrane, and the last layer is knit fabric.
The basic usage is for winter parka and raincoats.
ArDolu is certified for EN 343 and EN 20471
Standards & functions
Care instructions
Technical parameters19
| Parameter | Value | Method / standard |
|---|---|---|
| Fiber | 95% Polyester (PES) 5% Polyurethane (PU) | EN ISO 2076 |
| Yarn | 75 Denier | EN ISO 2060 |
| Weight | 210 ±10 g/m² | EN ISO 3081 |
| Width | 1500 ±20 mm | EN ISO 3932 |
| Tensile Strength | Warp > 1000N ; Weft > 800N | EN ISO 13934-1 |
| Tear Strength | Warp > 40N ; Weft > 35N | EN ISO 13937-2 |
| Dimensional Change | -3% < Length < +3% ; -3% < Width < +3% | EN ISO 5077 |
| Rubbing Fastness | 4-5 | EN ISO 105 X12 |
| Perspiration Fastness | 4-5 | EN ISO 105 E04 |
| Washing Fastness | 4-5 | EN ISO 105 C06 |
| Dry Cleaning Fastness | 4-5 | EN ISO 105 D01 |
| Hypochlorite Fastness | 4-5 | EN ISO 105 N01 |
| Hot Press Fastness | 4-5 | EN ISO 105 X11 |
| pH | 4,0 - 7,5 | EN ISO 3071 |
| Azo Test | No Azo Colorants. | EN ISO 14362-1 |
| Application | Raincoat | — |
| Quality Management | Done | ISO 9001 |
| Waterproof | Class 3,3 | EN 343 |
| High Visible | Yes | EN 20471 |
Colours & article numbers
| Colour | Code / PIND | Finish |
|---|---|---|
| Black | PT-95503-1 | STANDARD |
| Navy | PT-57753-1 | STANDARD |
| Green | PT-23603-1 | HIGH VISIBLE |
| Orange | PT-22970-1 | HIGH VISIBLE |
Applications
