ArBo Dark

58% para Aramid 40% Pbo 2% Carbon fabric, 220 gr/m'2

220 g/m², 58% p-Aramid 40% Pbo 2% Carbon, Inherent Flame Retardant, Antistatic, Plain Fabric

EN 1149EN 469OEKO-TEX 100
ArBo Dark

Description

World's strongest systhetic fabric which contains Pbo (poly phenylene benzobisoxazole)

220 g/m², 58% p-Aramid, 40% Pbo, 2% Carbon. ArBo Dark is designed for miltary application.

ArBo Dark is ultra fire resistant fabric

Flame resistant (Flame retardant) fabric with EN 469 certification.

Antistatic (EN 1149-5)

ArBo Dark is the best fabric in all categories for military applications.

Standards & functions

Oeko Tex Standard 100
Oeko Tex Standard 100
EN 469
EN 469
EN 1149-5
EN 1149-5

Care instructions

60'C Machine WashNo Chlorine Based BleachingCan Be Tumble Dried On Low Heat SettingMaximum 150'C Warm IronSuitable for Dry Cleaning

Technical parameters23

ParameterValueMethod / standard
Fiber58% p-Aramid (p-AR) 40% PBO (Pbo) 2% Carbon(CF)EN ISO 2076
YarnWarp:24/2Ne; Weft:24/2NeEN ISO 2060
Weight220 ±5 g/m²EN ISO 3081
Width1600 ±20 mmEN ISO 3932
Tensile StrengthWarp>5500N; Weft>5000NEN ISO 13934-1
Tear StrengthWarp>270N ; Weft>310NEN ISO 13937-2
Dimensional Change-3% < Length < +3% ; -3% < Width < +3%EN ISO 5077
Rubbing Fastness4-5EN ISO 105 X12
Perspiration Fastness4-5EN ISO 105 E04
Washing Fastness4-5EN ISO 105 C06
Dry Cleaning Fastness4-5EN ISO 105 D01
Hypochlorite Fastness4-5EN ISO 105 N01
Peroxide Fastness4-5EN ISO 105 N02
Hot Press Fastness4-5EN ISO 105 X11
Light Fastness4-5EN ISO 105 B02
Perspiration Light Fast.4-5EN ISO 105 B07
Weathering Fastness4-5EN ISO 105 B04
pH4,0-7.0EN ISO 3071
Azo TestNo Azo Colorants.EN ISO 14362-1
ApplicationMilitary Applications—
Quality ManagementDoneISO 9001
AntistaticYesEN ISO 1149-5
FirefightersYesEN ISO 469

Colours & article numbers

ColourFinishArticle no.
DarkSTANDARDArBo Dark-5889

Applications

Pbo 4 layer firefighter suit
Pbo 4 layer firefighter suit side
Pbo Dark 4 layer firefighter suit side

Other variants in this familyArBo · 2

ArBo

ArBo

220 g/m² · 58% p-AR 40% PBO 2% CF

ArBo Knit

ArBo Knit

250 g/m² · 58% p-AR 40% PBO 2% CF
