Catalogue · Aramid 2
Aramid D1 210 Denim
Aramid Denim Fabric, 93% meta Aramid 5% para Aramid 2% Carbon , 210 gr/m'2
210 g/m², 93% m-Aramid 5% p-Aramid 2% Carbon, Inherent Flame Retardant, Antistatic, Denim Fabric Aramid denim fabric
Description
210 g/m², 93% m-Aramid, 5% p-Aramid, 2% Carbon.
Inherent flame retardant fabric
for electricity distribution companies and oil and gas industry workers.
Inherent flame retardant fabric with EN ISO 11612 and EN ISO 11611 certification.
Antistatic (EN 1149-5) certified.
Protection against thermal hazards of electrical arc. (EN 61482-1-2)
Resistant to most industrial chemicals. (EN ISO 13034)
Standards & functions
Care instructions
Technical parameters26
| Parameter | Value | Method / standard |
|---|---|---|
| Fiber | 93% m-Aramid (m-AR) 5% p-Aramid (p-AR) 2% Carbon(CF) | EN ISO 2076 |
| Yarn | Warp:30/2Ne; Weft:30/2Ne | EN ISO 2060 |
| Weight | 210 ±5 g/m² | EN ISO 3081 |
| Width | 1600 ±20 mm | EN ISO 3932 |
| Tensile Strength | Warp > 1500N; Weft > 1000N | EN ISO 13934-1 |
| Tear Strength | Warp>70N ; Weft>60N | EN ISO 13937-2 |
| Dimensional Change | -3% < Length < +3% ; -3% < Width < +3% | EN ISO 5077 |
| Rubbing Fastness | 4-5 | EN ISO 105 X12 |
| Perspiration Fastness | 4-5 | EN ISO 105 E04 |
| Washing Fastness | 4-5 | EN ISO 105 C06 |
| Dry Cleaning Fastness | 4-5 | EN ISO 105 D01 |
| Hypochlorite Fastness | 4-5 | EN ISO 105 N01 |
| Peroxide Fastness | 4-5 | EN ISO 105 N02 |
| Hot Press Fastness | 4-5 | EN ISO 105 X11 |
| Light Fastness | 4-5 | EN ISO 105 B02 |
| Perspiration Light Fast. | 4-5 | EN ISO 105 B07 |
| pH | 4,0 - 7,5 | EN ISO 3071 |
| Azo Test | No Azo Colorants. | EN ISO 14362-1 |
| Application | Electricity distribution | — |
| Quality Management | Done | ISO 9001 |
| Flame and Heat Protection | Yes | EN ISO 11612 |
| Welding Protection | Yes | EN ISO 11611 |
| Antistatic | Yes | EN ISO 1149-5 |
| Arc Protection | Class 1 (4kA) | EN ISO 61482-1-2 |
| ATPV | > 7 cal/cm² | EN ISO 61482-1-1 |
| Chemical Resistant | Yes | EN ISO 13034 |
Colours & article numbers
| Colour | Article no. |
|---|---|
| Navy | PP-58628 |
| Grey | PP-96034 |
Applications
Send us your fabric specification.
Composition, weight, required standards, estimated volume — we respond with an offer, a technical data sheet and test results.
